Beschrijving
Productinformatie
WAN-verbinding | |
Ethernet WAN |
Ja
|
DSL WAN |
Ja
|
SIM-kaartsleuf |
Nee
|
3G/4G USB modem compatibiliteit |
Ja
|
Draadloos LAN | |
Wifi-band |
Dual-band (2.4 GHz / 5 GHz)
|
Wifi-standaard |
IEEE 802.11ac
|
WLAN gegevensoverdrachtsnelheid (max) |
867 Mbit/s
|
WLAN gegevensoverdrachtsnelheid (eerste band) |
450 Mbit/s
|
WLAN gegevensoverdrachtsnelheid (tweede band) |
867 Mbit/s
|
Aantal antenne’s |
3
|
Ethernet LAN-eigenschappen | |
Ethernet LAN |
Ja
|
Interfacetype Ethernet LAN |
Gigabit Ethernet
|
Ethernet LAN, data-overdrachtsnelheden |
10,100,1000 Mbit/s
|
Bekabelingstechnologie |
10/100/1000Base-T(X)
|
Poorten & interfaces | |
WAN-poort |
Ethernet (RJ-45)
|
USB-poort |
Ja
|
Aantal Ethernet LAN (RJ-45)-poorten |
4
|
RJ-11 ports kwantiteit |
1
|
Aantal USB 2.0-poorten |
1
|
Aansluiting voor netstroomadapter |
Ja
|
DSL-eigenschappen | |
ADSL |
Ja
|
ADSL2+ |
Ja
|
VDSL 2 |
Ja
|
Poorten & interfaces | |
Connectiviteitstechnologie |
Bedraad/Draadloos
|
Mobiel netwerken | |
3G |
Ja
|
4G |
Ja
|
Netwerk | |
Netwerkstandaard |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
|
Port forwarding |
Ja
|
Toegang voor gasten |
Ja
|
Beheerprotocollen |
SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools
|
VoIP protocollen |
IPv4, IPv6
|
Protocollen | |
DHCP client |
Ja
|
DHCP server |
Ja
|
DMZ support |
Ja
|
Antenne | |
Soort antenne |
Extern
|
Afneembare antennes |
Ja
|
Antennas quantity |
3
|
Draadloos LAN | |
Wi-Fi-standaarden |
IEEE 802.11a,IEEE 802.11ac,IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
|
Beheerfuncties | |
Reset button |
Ja
|
Quality of Service (QoS) |
Ja
|
Universal Plug and Play ( UPnP ) |
Ja
|
WPS Push Button Security |
Ja
|
Beveiliging | |
Ondersteunde beveiligingsalgoritmen |
64-bit WEP,128-bit WEP,WPA,WPA-PSK,WPA2,WPA2-PSK
|
Firewall |
Ja
|
Filtratie |
Ja
|
MAC adres filtering |
Ja
|
VPN tunnels quantity |
10
|
VPN eigenschappen |
PTP, L2TP, IPSec Passthrough
|
Design | |
Producttype |
ADSL/VDSL Modem/Router
|
Kleur van het product |
Zwart
|
Indicatielampje |
Ja
|
LED-indicatoren |
LAN, Stroom, WLAN
|
Aan/uitschakelaar |
Ja
|
Prestatie | |
Geheugenkaart slot(s) |
Nee
|
Energie | |
Type stroombron |
AC
|
Spanning |
12 V
|
Output current |
1,5 A
|
Gewicht en omvang | |
Breedte |
243,5 mm
|
Diepte |
167,5 mm
|
Hoogte |
32,7 mm
|
Eisen aan de omgeving | |
Temperatuur, in bedrijf |
0 – 40 °C
|
Temperatuur bij opslag |
-40 – 70 °C
|
Relatieve luchtvochtigheid, in bedrijf |
10 – 90 procent
|
Luchtvochtigheid bij opslag |
5 – 90 procent
|
Certificaten | |
Certificering |
CE, RoHS
|
Inhoud van de verpakking | |
Inclusief AC-adapter |
Ja
|
Meegeleverde kabels |
LAN (RJ-45)
|
Gebruikershandleiding |
Ja
|
Snelstartgids |
Ja
|
Type verpakking |
Box
|
Software | |
Ondersteunt Windows |
Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64,Windows Vista Business,Windows Vista Business x64,Windows Vista Enterprise,Windows Vista Enterprise x64,Windows Vista Home Basic,Windows Vista Home Basic x64,Windows Vista Home Premium,Windows Vista Home Premium x64,Windows Vista Ultimate,Windows Vista Ultimate x64,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
|
Ondersteunt Linux |
Ja
|
Ondersteunt Mac-besturingssysteem |
Ja
|
Overige specificaties | |
USB-versie |
2.0
|
Afmetingen (BxDxH) |
243 x 160.6 x 32.5 mm
|
Frequentieband |
2.4, 5 GHz
|
Type apparaat |
ADSL/VDSL Modem/Router
|
